EQUIPMENT AND MATERIAL INFORMATION
The equipment includes:
er- Compressor unit - Model: CONDOR F2000
n.
A1 - Switch, A2 - Air intake, A3 - Air filter, A4 - Nebuliser holder
A -
A5 - Carrying handle, A6 - Power cable
A7 - Cable storage compartment
Nebuliser and accessories - Model: RF9-1
B1 -Connecting tube (compressor/nebuliser unit)
B2 - RF9 Nebuliser
B2.1 - Lower part, B2.2 - Nozzle, B2.3 - Upper part
B2.4 - Complete particle size regulator
B2.4a - Regulator, B2.4b - Valve, B2.4c - Selector
B -
B3 - Mouthpiece Mouthpiece with valve
B3.1 - Expiratory valve, B3.2 - Non-invasive nosepiece
B4 - Adult SoftTouch mask
B5 - Paediatric SoftTouch mask
B9 - Nebulization manual control
IMPORTANT NOTE: There is an identification label on the packaging, remove it and affix it in the
spaces provided on page 2. When replacing the Nebuliser and accessories, perform the same
procedure.
4)
ASSEMBLING THE NEBULISER. Follow the assembly instructions below.
1. Assemble the nozzle (B2.2) on the upper part (B2.3). (Fig. 5,6)
2. Place the valve (B2.4b) with the flat side down onto the particle size regulator (B2.4a) by aligning
the hole with the position ribs, then screw the selector (B2.4c) onto the threaded pin of the regulator
all the way down. Rotate the assembled regulator to make sure that it turns freely and that the selec-
tor moves up and down between positions. (Fig. 7).
3. Insert and press the previously assembled particle size regulator (B2.4) all the way down, keeping it
nd
in a horizontal position, in the upper part (B2.3), and matching the partitions of the selector (B2.4c) with
he
the groove in the upper part (B2.3). (Fig. 8).
he
4. Insert the assembled upper part (B2.4 + B2.3 + B2.2) into the lower part (B2.1) and hook it by turning
it clockwise. (Fig. 9).
HOW TO USE THE RF9 NEBULISER WITH PARTICLE SIZE REGULATOR AND VALVE SYSTEM. It is
professional, quick, recommended for administering all types of medicinal products, even in patients
with chronic diseases. The valve system optimises the dispensing of the nebulised medicinal product
to the patient and limits its dispersion in the environment. Moreover, thanks to the particle size
regulator, the size of nebulised particles can be selected based on the respiratory system area where
the medication is to be delivered. Indeed, with the 4 available modes, the bowl can dispense particles
of different sizes.
Pa
Select the desired position by means of the particle size regulator B2.4.
By turning the regulator clockwise, the selector (B2.4c) moves and closes the opening, while it opens if
the regulator is turned anti-clockwise. (Fig. 10).
To use the bowl without selector, firmly grasp the bowl body and use your other hand to rotate the
e
particle size regulator (B2.4) clockwise until it is ejected from the upper part (B2.3). (Fig. 11).
o
Before each use, wash your hands thoroughly and clean your appliance as described in the
section "HYGIENE PREPARATION". During application, it is recommended to adequately protect
oneself from drips. This appliance is suitable for the administration of medicinal substances
(solutions and suspensions), for which aerosol administration is envisaged; such substances
must in any case be prescribed by a doctor. In the case of substances that are too dense, dilution
with suitable saline solution may be necessary, as prescribed by a doctor.
1. Insert the plug of the power cable (A6) into a mains socket corresponding to the voltage of the
appliance. It must be positioned in such a way that disconnection from the power grid is not difficult.
2. Pour the medication prescribed by the physician into the lower part (B2.1). Insert the upper part
(B2.4+B2.3+B2.2) of the bowl into the lower part (B2.1), then close the bowl by turning the upper part
OPERATING INSTRUCTIONS
15
Information on materials
Polypropylene
Polypropylene +
Thermoplastic Elastomers
Polypropylene
