DAZE Dazebox Home Installationsanleitung Seite 22

EN
13.1 - Reset of Internal Protections
14 - Maintenance
14.1 - RCBO Maintenance
Note: The image is indicative; the position of the Test button may vary, and the Reset button may not be present.
In case of problems, technical support can be contacted by opening a ticket. This can be done by
accessing the "Support" section of the App or through the "Contact Us" section of the Daze website.
Alternatively, the QR Code below can be used to directly access the contact form.
22.
Resetting the RCBO
If the residual current circuit breaker with overcurrent protection (RCBO)
trips, follow these steps to reset it:
1. Use the key to open the Dazebox Home panel as shown in the image.
2. Check the RCBO's position. If the switch is in the tripped position (lever
down), proceed to reset it by lifting the lever. If the RCBO trips again,
check the upstream line to identify any faults.
3. Close the panel and secure it using the key.
To ensure proper functioning of the residual current circuit breaker
with overcurrent protection (RCBO), it is necessary to perform a
periodic test (every 6 months) to verify the RCBO's operation in case
of a fault.
To perform the test, follow these steps:
A
1. Use the key to open the side panel, as indicated in section 13.1.
2. Ensure the RCBO is armed, meaning the lever (A) is in the upward
B
position.
3. Press the test button (B) (refer to the image).
C
The test is successful if, upon pressing the test button (B), the lever (A)
trips to the downward position. Otherwise, contact technical support.
After completing the test, press the reset button (C), if present, and
then return the lever (A) to the upward position.
