Simons Voss Technologies SmartHandle AX Advanced Kurzanleitung Seite 9

SmartHandle AX Advanced Panic fitting with wide
cover
7. Installing the fitting
16
17
*PS* (with backplate)
BKS (bar handle)
BKS (push bar)
CISA 8 mm spindle
CISA 9 mm spindle
Abbildungen/Images
Door thickness – 27.8 ± 1.5 mm
Door thickness – 36.8 ± 2.5 mm
Door thickness – 27.3 ± 0.5 mm
Door thickness – 19.3 ± 0.5 mm
PH2 TX25
*PO* (with round escutcheon)
BKS (push bar)
7. Installing the fitting
TX15
Door thickness + 36.8 ±2.5 mm
9 / 56
