Welcome to Trend Multipro Copper

This Quick Reference Guide will help you get started using the Copper PIM
with Trend Multipro to test and monitor Copper connections and cables.
Throughout this Guide we refer to Trend Multipro Copper as Trend Multipro
unless stated otherwise. See the Main Reference Guide and the On-line
Help on Trend Multipro for more information.

Safety Advice

Please refer to the Main Reference Guide.
WARNING

A Look at the Copper Components

Depending on the options that your organisation has purchased you may
have all or some of the following:
The main copper components required for testing are:
The Trend Multipro Platform. (See the Main Reference Guide and
•
the On-line Help on Trend Multipro for more information.)
The Copper PIM
•
Earth Cable
•
Probes (Active and Passive) and Line Pair Connector Cables
•
Testing Cables and Crocodile connectors
•
Trend Multipro Copper Power Supply
•
Trend Transponder and Cables (optional)
•
Pair Trace Probe (Optional)
•

Copper PIM

See the Main Quick Reference Guide for how to fit and remove the PIM.
405801 Iss 3
There may be High Voltage on the line. This may be in-
dicated when LED 3,flashes red. See LEDs on page 5
