Transponder

This is placed on the line under test and can be used for End-to-End test-
ing. You can connect up to 8 Transponders in series on the line. Only one
Transponder can be activated at a time during tests; so each Transponder
MUST be set to a unique address.
The Transponders are powered by 4 AA Dry Cells and can be left switched
on and connected to a line for long periods of time without affecting the
transmission of the service. It only becomes active when accessed by
Trend Multipro.
Note: When connecting the Transponder cables you must connect the
Black cable to the a-wire and the Red cable to the b-wire.
See Connection Methods on page 13. See also the On-line Help for more
information on using Transponders.
