Equipment Application
System (Equipment) tests are used for performing tests on active systems.

Connection Methods

You must connect Trend Multipro and its components correctly to the line
to be tested, or the test will not work properly. The following diagrams illus-
trate how to make the connections and are followed by a list of the tests
that use the connections shown. You must use the earth cable during the
Longitudinal Balance test and Metallic tests. Using the earth cable in other
tests is optional.
