TREND Multipro Copper Kurzbedienungsanleitung Seite 20

Passive Probe
Tx
Use for:
Far-End Crosstalk (FEXT)
•
405801 Iss 3
RJ-11 Line Connec-
tor 1
Active
Probe
Transponder
Tx / Rx
Connection Diagram 6
Interfering Line
Earth
-19-
Line Under Test
RJ-11 Line Connec-
tor 2
Earth
Multipro Copper
Short User Guide
GB
