TREND Multipro Copper Kurzbedienungsanleitung Seite 15

Passive Probe (not
in use)
Use for:
Voltage
•
Resistance
•
Insulation
•
Capacitance
•
Time Domain Reflectometer (TDR) Normal Mode
•
Return Loss
•
Longitudinal Balance
•
Impulse Noise
•
Noise
•
Load Coil Counter
•
Characteristic Impedance
•
Generator
•
Multipro Copper
Short User Guide
Connection Diagram 1
-14-
Line Under Test
Active Probe
Tx / Rx
Earth
405801 Iss 3
