2.10

Residual risks

Residual risks: Due to the design of the Pipe End Peelers, certain residual risks can not
be completely excluded. Read the following instructions carefully. This allows you to react
faster and safer in case of a problem!
3

Transport, Installation and removal, storing

Qualification of personnel. The tool may only be transported, installed, removed and
stored by persons with relevant professional experience and expertise in using the tool!
Safety. User and operator are responsible. Observe all safety instructions in this instruc-
tion manual as well as all valid safety regulations!
Transport damage:
Check the tool for damage immediately after receipt. If damage or abnormalities are present,
ideally document them with pictures and contact the manufacturer or your dealer.
Packaging:
The tool is delivered in a plastic suitcase. Keep the suitcase for transport and storage.
Damage to the plastic suitcase. Damage to the plastic suitcase may indicate damage to
the tool. If in doubt about the condition of the tool, contact the manufacturer or your dealer!
Assembly and installation:
Conditions for the installation site:
- Make sure you have enough space and good lighting.
- The pipe must be free of dirt and foreign objects.
- There must be no moisture near the power cord or power supply.
- Provide a free escape route in case you lose control of the tool during assembly.
- If necessary, set up a tent to protect the work area and the tool from the effects of the
weather, such as strong sunlight, rain or moisture.
Storage:
Store the product in its transport suitcase, protected from the weather. The temperature should
be between 10 and 30 ° C with a humidity of not more than 60%.
4

Technical Data

Code ............................................................. 1500004347 ........................ 1500004348
For pipe dimensions (mm) ........................... 90 to 315 ............................. 180 to 400
For pipe dimensions IPS .............................. 4-10 ..................................... 8-16
For pipe dimensions DIPS ........................... 3-10 ..................................... 8-14
Suitable for pipes made of ........................... PE, PE-X, PP ...................... PE, PE-X, PP
Peeling blade................................................ PES3 ................................... PES3
Peeling depth (mm) ...................................... 0,3 (0,25 to 0,35) ................. 0,3 (0,25 to 0,35)
Length of peeling at max. insertion depth .... ca. 125 mm ......................... ca. 170 mm
(Depending on the pipe size)
Product dimensions L×W×H (mm) ............... 500×260×100 ...................... 530×330×150
Product weight (kg) ...................................... 3,9 ....................................... 8
Packaging dimensions L×W×H (mm) ........... 590x140x390 ...................... 590x140x390
Packaging material ....................................... Plastic ................................. Plastic
Packaging type ............................................. Suitcase .............................. Suitcase
Packaging weight (kg) .................................. 2,8 ....................................... 2,6
Transport weight (kg) ................................... 7 .......................................... 10,6
Scope of delivery: Instruction manual, Base frame, Fastening key, 1 x Spare blade, Hex key
screwdriver 2 mm, ROCASE 6414 with foam insert
