CHARGE THE CONTROLLER BATTERY
The battery is removable and has an estimated run time of
about 30 hours. The battery charge level can be monitored
through the App and a low battery is also indicated by a
colored LED that blinks once when installing the battery onto
the controller and after each lever press:
Yellow LED: 10-25%
Red LED: less than 10%
To charge the battery on the controller, follow the instructions
below.
1.
To remove the battery from the controller, disengage the
latch and rotate the battery out (see Figure A). When
the battery is removed from the controller, install the
protective cover (shaped like a "dummy" battery) to
protect the controller.
Do not discard the controller's protective cover. This protective
cover is critical for protecting the controller when the battery
is not connected (for example, during charging off the bike,
storage, or transport). If left uncovered, the controller can
sustain damage through exposure to elements such as water
and debris.
2. Plug the charging cable into a USB power supply. Then
plug the charging cable into the charger (see Figure B).
Install the battery onto the charger and close the latch to
secure it (see Figures B and C).
3. The red charging LED will illuminate during charging.
The green LED will illuminate when battery charging
is complete (approximately 1.5 hours). 15 minutes of
charging yields approximately 1.5 hours of additional run
time. Do not leave the battery plugged into the charging
cable after charging is complete (i.e. overnight or for long
periods unattended).
4. Remove the protective cover from the controller and store
it in a safe place.
5. To install the battery onto the controller, place the battery
on the mount of the controller. While pressing the battery
into the controller, close the latch to secure it to the
controller (see Figure D).
NOTICE
A
B
C
D
7
