INSTALL THE SEATPOST
Be sure to refer to the owner's manual for your bicycle. FOX products
should be installed by a qualified bicycle service technician, in
accordance with FOX installation specifications. Improperly installed
FOX products can fail, causing the rider to lose control, resulting in
SERIOUS INJURY OR DEATH.
1. Insert the seatpost into the seat tube with the proper orientation
(use friction paste for carbon frames if needed). Install the seatpost
into the frame past the minimum insertion line that is on your
specific seatpost.
The Transfer Neo seatposts are directional and proper orientation has
the lower of the two upper post saddle clamp fastener locations facing
forward.
2. Use the remote lever to check that the seatpost properly moves into
all positions.
3. Set the seatpost to the desired height and tighten the seat collar
binder bolt to a maximum of 44 in-lb (5 N•m), as shown in Figure H.
Make sure the "Minimum Insertion Line" on the seatpost is inserted
past the seatpost collar binder bolt, as shown in Figure G. Check
again that the seatpost properly moves into all positions.
The maximum torque for the Transfer Neo seatpost collar binder bolt
is 44 in-lb (5 N•m). Actual required torque will depend on rider weight,
bike frame, and type/brand of seatpost/seat collar. Correct torque will
support the rider and not interfere with seatpost function. If the torque
is too high, the seatpost may not return fully from all positions or may
not move up and down properly. If the torque is too low, the seatpost
may not support the weight of the rider or may not remain stationary
at the seat tube. Failure to use the proper torque for your seatpost/seat
collar combination can result in loss of control, resulting in SERIOUS
INJURY OR DEATH.
Regardless of bicycle frame tube configuration, the best structural
support is achieved when the Transfer Neo seatpost is inserted at least
to 1) the minimum insertion mark on the seatpost, AND 2) the minimum
insertion point specified by the manufacturer of your bicycle frame.
Neglecting these two items risks causing damage to the frame and
seatpost, resulting in SERIOUS INJURY OR DEATH.
WARNING
WARNING
WARNING
WARNING
12
G
Minimum
Insertion
Line
H
44 in-lb (5 N•m)
