Carabiners: carabiners must be used as shown in chart A and fig.5-6. For Vortex, the assembling of O-Ring rubbers is
shown in fig.7. For Matrix Comp, the assembling of Karstop rubbers is shown in fig.8. Warning: certain situations may
reduce the strength of the carabiners (fig.6b).
CHECKING
Check that the energy absorber [1] is in its original configuration as indicated in fig.11.
During use, avoid contact of the sling with sharp edges to avoid the breaking strength decreasing or cuts. Humidity,
intense cold, exposure to UV rays, and the aging due to use can reduce the resistance of the sling.
A carabiner looses half of its resistance when the gate is open (see chart A). It is recommended to check that the gate is
properly working before use:
Ÿ if the gate [9] does not come back properly when closing. During the inspection, the gate [9] should be released slowly
in order to nullify the spring action.
Ÿ wrong or incomplete functioning of the gate closing system [9]. Never use a carabiner if it is just partially blocked. The
automatic closing must be carried out completely, without any external aid. In certain environments, contaminants
(mud, sand, paint, ice, dirty water, etc.) can prevent the automatic locking system from working.
If one of the defects appears, after cleaning, oil the gate mechanism with a silicon based lubricant. Note: cleaning and
lubrication is recommended after every use in marine environment. If, after oiling, the defect persists, the carabiner has to
be put out of use.
REVISION
In addition to the normal inspection required before, during and after each use, this product must be inspected by a skilled
person at least every 6 months, starting from date the product is first used; this date and the subsequent checks must be
recorded on the product's life sheet: keep this literature for inspection and reference for the life of the device. Check the
legibility of the product's markings.
In case of one of the following defects are present, the Set ferrata should be withdrawn from service immediately:
Ÿ presence of cutting and/or burning on the sling
Ÿ presence of cutting and/or burning on the seams
Ÿ presence of crack(s) on the metal absorbing element [6]
Ÿ deployment of the energy absorber [1] (fig.10)
In case of one of the following defects are present, the carabiner should be withdrawn from service immediately:
Ÿ deep corrosion that seriously alters the surface state of the metal (which does not disappear after a light rubbing with
emery paper)
Ÿ play or exit of the rivet from the gate [9] of the carabiner
Ÿ incorrect placement of the gate [9] on the carabiner body [8]
Ÿ play or exit of the rotation axis of the fate [11]
Ÿ general wear and tear of the body [8] which causes a significant reduction of the body section, which is deeper than
