Motor
Pos. Part. no.
Designation
1 SB
Oil housing with seal, oil seal cover,
shoulder bearing
2 SB
Stator (HP 10/122)
3 SB
Motor shaft with rotor (HP 10/122)
4 SB
6 x 6 x 20 parallel key
5 SB
Motor bearing B-side Z-bearing
6 SB
Motor bearing A-side shoulder bea-
ring
8 SB
25 x 35 x 7 oil seal
9 SB
Fan wheel
10 SB
Fan hood
11 SB
Flat seal
12 SB
5-pin luster terminal
13 SB
Switching unit lower part
14 SB
Switching unit cover with seal
58
Qty.
1
No pic-
SB
ture
15 SB
1
16 SB
1
18 65 65 64
1
19 SB
1
20 SB
1
21 SB
22 SB
1
1
23 SB
1
24 SB
1
25 SB
28 SB
1
40 SB
1
41 SB
1
Seal with switching unit cover
PG 11 jam nut
PG 11 cable gland with kinks
40 µF capacitor
Power cable for 230V
3.5 x 9.5 tapping screw
2.9 x 16 tapping screw
4.8 x 16 tapping screw
3.9 x 9.5 tapping screw
Complete earthing screw
M6x30 hex socket screw
12A switch (HP 10/122)
Cpl. motor for HP 10/122
Complete switching unit for HP
10/122
Translation of the original instruction
