Storch 120 Compact Originalbetriebsanleitung Seite 50

Table of contents
1. Technical data
2. Appliance description / Function
3. Water and cleaning/care agent system
4. Spray gun with wash lance
5. Pressure control safety valve
6. Installation: Location
7. Brief operating guide
8. Commissioning
9. Pressure settings
10. Decommissioning
11. Safety precautions
12. Troubleshooting aids
13. Spare parts list
14. Tests
15. Warranty / warranty conditions
16. EC Declaration of Conformity
Intended use
The high pressure cleaner is suitable for outdoor cleaning work on hard and water pressure resistant substrates. Examples: Cleaning
outside walls, pavement slabs, drives, rocks, etc.. The locally applicable waste water and discharge regulations must be observed at all
times.
Responsibility of the operating company
The operating company must ensure the following:
• The device must only be used in the intended manner.
• The device must be maintained in accordance with the specifications in this operating manual.
• The device must only be operated in accordance with local guidelines and occupational health and safety regulations.
• All precautions are taken to avoid dangers arising from the device.
• All precautions are taken for first aid care and fire fighting.
Organisation/personnel
Operators
• Before starting to use the device, the operator must have read and understood the operating manual.
• Only authorised and trained operators must have access to the device in order to operate it.
• The operating manual must be available to the operator at all times.
• The operator must not be under the influence of alcohol, drugs or medication.
• Children, performance-impaired persons, and pregnant women are not allowed to operate the device.
Scope of delivery
High pressure cleaner, 10 m high pressure hose, wash lance with quick coupling, operation manual.
Technical specifications
Working pressure, infinitely variable
Permissible overpressure
Water volume flow
Hot water infeed
Suction height
High pressure hose
Rated load
Output
Weight (without options)
Nozzle size
Sound power level
Recoil at lance
Vibrations at lance
All information is without guarantee! Subject to technical modifications and errors!
50
30 - 120 bar
135 bar
10 l / min at 2,800 rpm
up to 60° C
1 m
10 m
230 V / 50 Hz, 11 A
2,500 W
23 kg
20042
measured: 71 dB (A)
warranted: 91 dB (A)
approx. 27 N
1.9 m/s
2
Translation of the original instruction
Page
51
51
51
52
52
52
53
53
54
54
54
56
57
60
60
61
