4.13 Transducer Block Diagnostics - Slot 14
Der Messumformer verfügt über Prozess-Diagnose-Funktionen. Diese sind in dem Tranducer
Block „Diagnositics" gebündelt.
Relative
Index
0...7
Standard Block Parameter
8
SNR_VALUE
9
REFERENCE
10
SIGNAL_RATIO
11
SIGNAL_MAX
12
SIGNAL_MIN
13
SIGNAL_ERROR
14
NV_RESETS
15
AMPLIFICATION_INTERNAL
16
EMPTY_PIPE_ON_OFF
17
EMPTY_PIPE_THRESHOLD
18
EMPTY_PIPE_DETECTOR
19
EMPTY_PIPE_ADJ_START
20
EMPTY_PIPE_ADJ_PROGRESS
21
EMPTY_PIPE_ADJ_FAIL_INFO
22
EMPTY_PIPE_MAN_ADJ_FULL
23
TFE_ELECTRODE_AVAILABLE
24
TFE_DETECTION_ON_OFF
25
TFE_THRESHOLD
26
TFE_ADJ_START
27
TFE_ADJ_PROGRESS
28
TFE_ADJ_FAIL_INFO
29
TFE_DETECTOR
30
SIL_DIAG_ON_OFF
31
SENSOR_MEASURE_ON_OFF
32
SENSOR_TEMP_CALIB
33
SENSOR_TEMPERATURE
34
SENSOR_CABLE_LENGTH
35
SENSOR_TEMP_MAX_ALARM
36
SENSOR_TEMP_MIN_ALARM
37
COIL_CURRENT_VALUE
38
COIL_RESISTOR
39
COIL_VOLTAGE
40
COIL_RESISTOR_MAX_ALARM
41
COIL_RESISTOR_MIN_ALARM
42
GAS_BUBBLE_ON_OFF
COM/FEX300/FEX500/PB-DE
Parametername
FEX300, FEX500
Object
Data Type
Type
Simple
Float
Unsigned32
Unsigned16
Unsigned8
Unsigned16
Float
Unsigned8
Unsigned16
Unsigned8
Unsigned16
Unsigned8
Float
DS-101
Float
Unsigned8
Block-Übersicht
Store Bytes
Access
D
4
r
D
4
r
D
2
r
D
2
r
D
2
r
D
2
r
D
2
r
D
1
r
S
1
r,w
S
2
r,w
D
4
r
D
1
w
D
1
r
D
1
r
D
1
r,w
N
1
r
S
1
r,w
S
2
r,w
D
1
w
D
1
r
D
1
r
D
2
r
S
1
r,w
S
1
r,w
S
4
r,w
D
5
r
S
4
r,w
S
4
r,w
S
4
r,w
D
4
r
D
4
r
D
4
r
S
4
r,w
S
4
r,w
S
1
r,w
