_________________________________ ___EN__________________________________35
main unit. Please, ensure drainage of condensate water. In this case, it is
recommended to mount the heat insulation layer outside the air duct outlet.
Putting into operation HB200(C) hot water tank in a closed space.
It is forbidden to operate HB200(C) hot water tank outdoor or exposed to rain or
moisture.
If the HB200(C) hot water tank is connected to air duct reaching to outdoor, reliable
water-resistant protection needs to be ensured for the air duct, to avoid that rainwater
enters the appliance.
Figure 7.2.-5.
Rain
Figure 7.2.-6.
Rain
Air inlet
