5) After the heater is replaced, please do the following measurements:
6) Calibrate the temperature, refer to
Soldering temperature
NOTE: Do not burn the wiring when you
replace the heater and do not solder the wiring
for too long time.
2.14.
1) Place the selected nozzle inside the steel pipe of the air outlet of the handle,
and the four positioning catches on the nozzle must enter the installation slot of
the steel pipe.
2) Lock the nozzle with the wrench provided and turn it clockwise. The two Fixing
points of the wrench are placed in the two slots of the nozzle.
3) To disassemble the nozzle, just use a wrench to lock the nozzle and turn it
counterclockwise to take out the nozzle.
Nozzle
calibration.

Hot Air Nozzle

13
A2025
A2064
A2084
USER MANUAL
