2.11.
2.11.1 Soldering Tip Calibration
1) Set the temperature to 350°C.
2) When the temperature is stable, use the
temperature tester to measure the temperature of the
soldering tip and write down the readings.
3) Press and hold the "
the soldering station enters the temperature calibration mode.
4) Press " " or "
temperature.
Long press " " and "
NOTE: It is recommended to use QUICK 191/192 series temperature tester to
measure the soldering tip temperature.
2.11.2 Hot Air Calibration
1) Set the hot air temperature to 300 ℃.
2) Press and hold the "▼ " button on the left and right
side at the same time to enter the temperature
calibration mode.
3) When the temperature is stable, use the temperature tester to measure the
temperature. Press "
" and " " buttons to confirm, and return to the main menu at the same
time.
Note: It is recommended to use QUICK 196 series hot air temperature tester to
measure temperature.

Temperature Calibration

" buttons on the left and right side at the same time:
" button to change the value of the soldering station
" button to save.
" or " " to change the hot air temperature. Long press"
