2.6.2 Hot Air
1. Before first use, the tray for the hot air pen must
be mounted. It can be mounted on the left or right
side.
2. Remove 2 screws from the side of the station.
3. Fasten the tray to the station with both screws.
4. Place the hot air piston in the tray.
NOTE: After the hot air piston has been placed in the tray, the temperature is
cooled down to 100°C. The hot air piston then switches off. The hot air piston
then switches off.
As soon as the hot air piston is removed from the tray, it heats up to the
previously set temperature.
2.6.3 Connections
Connect the power supply to the station, turn on the power switch and the
station to work.

2.7. Temperature Setup

2.7.1 Hot Air Temperature
Press "▲" und "▼" button (left) in the working modus and
the temperature will go up or down in 1°C after each press.
2.7.2 Soldering Station Temperature
Press "▲" und "▼" button (left) in the working modus and
the temperature will go up or down in 1°C after each press.
