FEP630, FEH630 MAGNETISCH-INDUKTIVER DURCHFLUSSMESSER | COM/FEP630/FEH630/E/MB-DE REV. B
Gerätestatus FEP63x/FEH63x -> SPS
(T->O)
104 (Extended_Device_Status)
Device_Status
Mass_flowrate_exceeds_limits_0_0
Volume_flowrate_exceeds_limits_0_1
Simulation_is_on_0_2
Flowrate_to_zero_0_3
Maintenance_interval_is_reached_0_4
All_totalizer_stop_0_5
Totalizer_reset_0_6
Display_value_is1600h_at_Qmax_0_7
Device_not_calibrated_1_0
Sensor_memory_defective_1_1
NV_data_defect_Data_storage_1_2
No_Frontend_Board_detected_1_3
FEB_communication_error_1_4
Incompatible_Frontend_Board_1_5
NV_chips_defect_on_Motherboard_1_6
Pulse_output_is_cutted_off_1_7
Current_output_3132_is_saturated_2_0
CurrOut_V1V2_V3V4_saturated_2_1
CurrOut_3132_com_error_2_2
Option_Card_1_com_error_2_3
Option_Card_2_com_error_2_4
Safety_Alarm_CurrOut_3132_2_5
CurrOut_3132_not_calibrated_2_6
CurrOut_V1V2_not_calibrated_2_7
CurrOut_V3V4_not_calibrated_3_0
MB_voltages_outside_range_3_1
An_alarm_is_simulated_3_2
Communication_card_not_responding_3_3
Co3132Uco_curr_loop_readback_failure_3_4
Coil_regulation_error_3_5
Coil_wiring_Detection_3_6
Coil Impedance measurement_3_7
Electrode short circiut detection_4_0
Electrode open circiut detection_4_1
DC Feedback Regulation Error_4_2
Monitoring Comm ADC and RX210_4_3
Coil Isolation_4_4
Gas bubble alarm_4_5
Conductivity exeeds limits_4_6
Sensor Temperature exeeds limits_4_7
TFE alarm_5_0
EPD alarm_5_1
ADC Signal overrange_5_2
SIL self check alarm_5_3
Inhouse temeprature exceeds limits_5_4
Ausgang SPS-Baugruppe ->FEx (O->T)
110 (Ausgang)
DO_Function_Activation
DO_Flow_To_Zero
DO_System_Zero_Adjust
DO_Counter_Reset
DO_Counter_Stop
DO_Dual_Range_Mass
DO_Dual_Range_Volume
