27.3.2 Keyboards/Keys
To clean the keyboards/keys of modules, always switch the Mobile Handheld Computer off since the
keyboards/keys react to being touched and the active program can therefore be compromised or interfered
with. Do not put a lot of pressure on the keyboards/keys.
27.4 Other
EU Directive on the Disposal of Waste Electrical and
Electronic Equipment (WEEE, Waste Electrical and Electronic Equipment)
All components must be returned to ACD Elektronik GmbH
at the end of their service life for recycling.
WEEE: 53473276
27.5 Attaching and Removing the Modules
27.5.1 Dummy Adapter
The dummy adapter (left/right) can be attached to the device or removed from the device using three screws.
A Torx screwdriver T20 is required to loosen or tighten the screws. The tightening torque is 0.5 Nm.
Fig. 42: Attaching and removing the dummy adapter
28 Other Accessories
28.1 DS2Battery Charging Box (2-fold)
Housing with LED indicators for charging two replacement batteries of the M2Smart
Fig. 43: DS2Battery charging box (2-fold)
The DS2Battery (2-fold)
Fig. 44: Connection set – 36 W for DS2Battery charging box (2-fold)
®
M2Smart SE 10 Zoll_M2Smart
charging box can
®
SE_10 Inch_Kurzübersicht_Brief Overview_V1.00_de_en
be operated with the following connection
®
SE 10 Inch.
set.
