19.1.5 Keyboard/Keys
Type
Layout
Fig. 25: Description of keys
19.1.6 Changing the Rechargeable Battery
The rechargeable battery compartment is on the back of the device. There are two battery compartments
here. The left-hand battery compartment (see illustration below) is electrically connected. The right-hand
battery compartment serves as a spare battery compartment. Open the rechargeable battery cover by
pressing the lock toward the surface of the rechargeable battery. The cover can be opened and the
rechargeable battery removed.
1. Electrically connected battery compartment
2. Spare battery compartment (not electrically connected)
1
Fig. 26: Description of battery compartments
®
M2Smart SE 10 Zoll_M2Smart
Left (black) On/Off button
Right (orange) top key
®
SE_10 Inch_Kurzübersicht_Brief Overview_V1.00_de_en
Keyboard
2
