19.3 Mounting Bracket
The mounting bracket of the M2Smart
versions. Please note the following warnings:
The mounting bracket may only be used for its intended function.
ATTENTION
The mounting bracket must be attached with sufficient stability to
support the weight of the M2Smart
ATTENTION
19.3.1 Installation/Mounting instructions
The mounting bracket can be attached to the wall using the mounting holes.
Fig. 32: Mounting the mounting bracket
Connect the Active mounting bracket to the power supply via the DC socket using the power supply unit or
DC connection cable provided.
To secure the power supply unit/DC connection cable, the cable can be fastened via the eyelet in the sheet
metal.
Fig. 33: Active mounting bracket connection
®
M2Smart SE 10 Zoll_M2Smart
®
SE 10 Inch for secure wall mounting is available in two different
Hole diameter 6mm
®
SE_10 Inch_Kurzübersicht_Brief Overview_V1.00_de_en
®
SE 10 Inch.
