Insert the M2Smart SE 10 Inch horizontally into the mounting bracket from above. Make sure that the device
is properly inserted into the guide pin on the bottom.
Fig. 34: Mounting bracket insertion diagram
19.3.2 Active Mounting Bracket
®
The Active mounting bracket is used to charge and stow the M2Smart SE 10 Inch in the attached mounting
bracket.
Fig. 35: Active mounting bracket
19.3.3 Passive Mounting Bracket
®
The passive mounting bracket is used to stow the M2Smart SE 10 Inch in the attached mounting bracket.
Fig. 36: Passive mounting bracket
® ®
