21.2 Active/Passive Mounting Bracket
The table below includes the technical data for the Activate/Passive mounting bracket:
Housing
Protection Class
Operating
Temperature
Storage
Temperature
Device Dimensions
Weight
Power Supply
Interfaces
22 Dimensions
®
22.1 M2Smart SE 10 Inch Mobile Handheld Computer
The dimensions of the M2Smart
Fig. 39: Dimensions of M2Smart
®
M2Smart SE 10 Zoll_M2Smart
Active Mounting Bracket
IPX5
530 g
15/24 V DC, 36 W
®
SE 10 Inch are shown below:
®
SE 10 Inch with blind caps
®
SE_10 Inch_Kurzübersicht_Brief Overview_V1.00_de_en
Technical Data
Passive Mounting Bracket
ABS + sheet metal
-
-20 °C to 50 °C/-4 °F to 122 °F
-20 °C to 60 °C/-4 °F to 140 °F
Approx. 124 x 270 x 112 mm (L x W x H)
500 g
-
DC socket
