22.2 Active/Passive Mounting Bracket
The dimensions of the Active and Passive mounting brackets are shown below:
Fig. 40: Dimensions of Active mounting bracket
Fig. 41: Dimensions of Passive mounting bracket
23 Instructions for Cleaning and Care
Clean the mobile handheld computer by setting it down on a surface (e.g. table). This way, you can hold it
securely and the Mobile Handheld Computer cannot slip out of your hands during the cleaning process.
Do not use corrosive chemicals, cleaning solutions or harsh
cleaning agents to clean the Mobile Handheld Computer,
rechargeable battery and mounting bracket.
ATTENTION
23.1 Display
Since the display reacts to touch and the active program can thus be affected or disturbed, always turn off
®
the M2Smart SE 10 Inch or press and hold the On/Off button for two seconds to put the device in Suspend
mode.
Never clean the touchscreen of the M2Smart
solvents, scouring agents or sponges. Doing so may damage the
touch surface! Do not put a lot of pressure on the display.
ATTENTION
®
When the M2Smart SE 10 Inch is delivered, a transport film has been applied to the display.
®
An M2Smart SE screen protection film for the 10.1 Inch display is also available as an accessory.
23.2 Window for Camera and Camera Lighting
In case of abnormalities during scanning, turn the Mobile Handheld Computer off and clean the scanner
pane with a soft, dry cotton cloth. The scanner pane is very transparent and barely visible to the naked eye.
Do not put a lot of pressure on the glass.
®
