7.7
AC input specification
7.7.1
General specification
Parameter
Earth systems
Safety
Frequency
Overvoltage category
Required external
surge protection.
7.7.3
230 VAC, 1-phase (IEC models)
HOME BASIC / HOME RFID
U1 – 230 VAC, maximum 264 VAC.
230 VAC, 1-phase (IEC models)
CLUE
U1 – 230 VAC, maximum 264 VAC.
7.7.4
AC input specification (IEC models)
Parameter
Input voltage (3 phases)
Input voltage (1 phase)
Input connection
AC power supply
Power consumption
In standby mode
Protection against
current leakage to earth
Maximum input power
(3-phase)
Maximum input power
(1-phase)
Specification [mm]
TN-S, TN-CS
50 Hz
Category III
Overcurrent, Overvoltage,
Earth fault, including
the flow of direct current
Specification [mm]
400 VAC
230 VAC
1 phase or 3 phases
maximum 2.8W
6 mA DC
11 kW (16 A)
22 kW (32 A)
3.7 kW (16 A)
7.4 kW (32 A)
7.7.2
400 VAC 3-phase with neutral conductor (TN) (IEC models)
HOME BASIC / HOME RFID
400 VAC 3-phase with neutral con-
ductor (TN) (IEC models)
CLUE
U1 – 230 VAC, maximum 264 VAC.
U2 – 400 VAC, maximum 460 VAC.
230 VAC, 1-phase (IEC models)
IOT
U1 – 230 VAC, maximum 264 VAC.
U1 – 230 VAC,
maximum 264 VAC.
U2 – 400 VAC,
maximum 460 VAC.
230 VAC, 1-phase (IEC models)
BUSINESS
U1 – 230 VAC, maximum 264 VAC.
400 VAC 3-phase with neutral con-
ductor (TN) (IEC models)
BUSINESS
U1 – 230 VAC, maximum 264 VAC.
U2 – 400 VAC, maximum 460 VAC.
400 VAC 3-phase with neutral conductor (TN)
(IEC models)
IOT
U1 – 230 VAC, maximum 264 VAC.
U2 – 400 VAC, maximum 460 VAC.
25
