2.4
Options
2.4.1
EV charging cable
(type 2)
2.5
Controls
2.5.1
LED indicators*
LED colour
Green
Green
Green
Green
Green
Blue
Red
Red
Red
Red
Purple
White
Yellow
* not applicable to the Business version
3.
Safety
3.1
Liability
The manufacturer is not liable for any damages, losses, costs or ex-
penses incurred by the purchaser of EVSE or third parties if the fol-
lowing principles are not respected by each target group mentioned
in the attached documents:
•
Follow the instructions provided in this document.
•
Use EVSE appropriately.
•
Do not make changes to EVSE without written consent from the
manufacturer.
EVSE is used to connect and transmit information and data via a net-
work interface. The owner is solely responsible for establishing and
continuously ensuring a secure connection between the EVSE and the
owner's network or another network.
The owner shall ensure and implement all appropriate measures
(such as, among others, the installation of firewalls, use of authen-
tication measures, data encryption and installation of anti-virus pro-
grams) to protect EVSE, the network, system and interface against all
security threats, unauthorised access, interference, hacking, leakage
and/or theft of data or information.
The manufacturer is not responsible for any damages and/or losses
resulting from such security threats, unauthorised access, interfer-
ence, hacking, leakage and/or theft of data or information.
20
2.4.2
LED status
Description
Continuous lighting
Fast flashing
Waiting for the RFID card
Continuous lighting
Vehicle connected
Fast flashing
Vehicle fully charged
Very fast flashing
RFID card error (on Home RFID
Pulsating
Loading in progress
Very fast flashing
Control model startup error. Check
power supply.
Slow flashing
Short circuit in the communication
Very fast flashing
DC leakage detected, charging
Fast flashing
Charging socket damaged
Fast flashing
Issue with PP line (damaged socket)
Fast flashing
Damaged electromagnetic lock
Slow flashing
Overload, DLB mode activated
Socket (type 2)
2.4.3
Readiness
version)
line to PE
Explanation: Very fast flashing: 5 /per 1 sec. | Fast flashing: 2 /per 1 sec. |
interrupted
Slow flashing: 1 /per 1 sec.
3.2
3.3
3.4
Load management (optional for selected EVSE versions)*
The load management function ensures that the maxi-
mum electrical load capacity of the building or house is
not exceeded. All devices are connected to a network
that has a certain maximum load capacity. The sum of the
power consumed by all devices using the network cannot
exceed this value. Thanks to the load management func-
tion, the system will not exceed the load capacity of the
network, which prevents fuse damage. In times of high
energy demand, EVSE reduces the output current. The
current will be increased again when network availability
is restored. Additionally, the load management function
ensures optimal distribution of the available load.
*Option available on selected EVSE versions.
Additional settings are required.
Contact your Lenergizee distributor.
Required installer qualifications
•
The installer has qualifications in accordance with locally
applicable regulations.
•
The qualified installer is fully knowledgeable about EVSE
and its safe installation.
•
The qualified installer adheres to all local regulations
and guidelines included in the installation instructions.
•
It is the duty of the EVSE owner to ensure that all qual-
ified installers comply with local rules, installation in-
structions, and EVSE specifications.
Installer's PPE
•
Protective clothing;
•
Protective gloves;
•
Safety shoes;
•
Protective glasses.
General safety instructions
This document, related documents, and the warnings con-
tained within them do not exempt the user from the obliga-
tion to exercise caution when working with EVSE.
•
Only undertake tasks for which the user is qualified and
as described in the relevant documents.
•
Local regulations and recommendations given in this
manual must both be observed. If local regulations con-
flict with the contents of this manual, local regulations
take precedence.
If permitted by law, in the event of any inconsistency or con-
flict between the requirements or procedures outlined in
this document and local regulations, always adhere to more
stringent requirements and procedures contained in both this
document and local regulations.
GREEN
ZIELONY
BLUE
NIEBIESKI
RED
CZERWONY
