NAMUR Instructions
IN_NAME
IN_PV_X X=1;2;3;4;5;7;8;
IN_SOFTWARE
IN_SP_X X=1;2;3;4;7;8;12; Reading the set rated value
42;50;52;53;54;55;56;
IN_TYPE
OUT_NAME name
OUT_SP_12@n
OUT_SP_42@n
OUT_SP_X n X=1;2;4;7;
50;52;53;54;55;56
OUT_WD1@m
OUT_WD2@m
RESET
RMP_CONT_X X=1;4
RMP_IN_X X=1;4
RMP_INX_y X=1;4
RMP_LOOP_RESET_X
X=1;4
RMP_LOOP_SET_X
X=1;4
RMP_OUT_X_yn X=1;4
hh:mm:ss
RMP_PAUSE_X X=1;4
RMP_RESET_X
RMP_START_X X=1;4
RMP_STOP_X X=1;4
START_X X=1;2;4;5;7
START_X X=16
STATUS_X
STOP_X X=1;2;4;5;7
Function
Input description name
Reading the real value
Input software ID number, date and version
Input laboratory unit ID
Output description name. (Max. 6 characters, default: IKAMAG)
Setting the WD safety temperature with the echo of the set value
Setting the WD safety speed with the echo of the set value
Setting the rated value to n.
Watchdog mode 1: When a WD1 event occurs, the heating and stirring functions are shut-
down and message ER 2 is displayed.
Set the watchdog time to m (20...1500) seconds, with echo of the watchdog time. This
instruction starts the watchdog function and must be sent within the set watchdog time.
Watchdog mode 2: When a WD2 event occurs, the speed setpoint will be set to the WD
safety setpoint speed and the temperature setpoint will be set to the WD safety setpoint
temperature. The WD warning is displayed. The WD2 event can be reset with
OUT_WD2@0 - resetting also blocks the watchdog function. Set the watchdog time to
m (20...1500) seconds, with echo of the watchdog time. This command starts the
watchdog function and must be sent within the set watchdog time.
Switching off the instrument function.
Continuaton of ramp function (After prior RMP_PAUSE_X).
Reading the real segment number of ramp. With ramp not started: 0
Reading the accumulated value and the ramp segment duration of ramp segment y.
Ending of ramp loop.
To work off the ramps in one loop.
Setting the accumulated value (n) and the ramp segment duration (hh:mm:ss)
for ramp segment y.
Stopping the ramp function. Freezing of real rated value and real ramp segment time.
Switching off ramp functions and deleting of all set ramp segments.
Starting the ramp function, beginning with ramp function No.1 (Only possible after prior
START_X. After RMP_STOP_X ist START_X is not necessary.
Switching off ramp function. Rated value = 0. (Ramp is maintained, that means, ramp can
be restarted with RMP_START_X).
Starting the instrument's (remote) function
Activation of the "watchdog" function. If no rated value is entered given in the next
60 seconds, the heating is switched off..
Display of status
1S: mode of operation A
2S: mode of operation B
3S: mode of operation C
S0: manual operation without fault
S1: Automatic operation Start (without fault)
S2: Automatic operation Stop (without fault)
<0: error code:
Switching off the instrument - (remote) function.
Variables set with OUT_SP_X are maintained. Contains the instruction RMP_STOP.
(-1)
- 1: error 1
- ... (see table)
-31: error 31
-83: wrong parity
-84: unknown instruction
-85: wrong instruction sequence
-86: invalid rated value
-87: not sufficient storage space
Display
(additional)
REMOTE
REMOTE
