English
15.3 Legend
Shutoff valve
Three-way mixer
Circulating pump
Expansion vessel
Room temperature-controlled valve
Shutoff valve with check valve
Shutoff valve with drainage
Safety valve combination
Heat consumer
Temperature sensor
Flexible connection hose
Check valve
Heat pump
Hydro tower
Immersion heater
17
Heat circulating pump for heating
circuit
Heat circulating pump for heating
E10.1
circuit 2
M13 Auxiliary circulation pump
M15 Hot water loading pump
M16 Mixer for main circuit or heating circuit 3
M21 Mixer for heating circuit 2
M22 Heat pump manager
N1 External wall sensor
R1 Return flow sensor (integral)
R2 Temperature sensor for heating circuit 2
Sensor for heating
R5
renewable sensor
R13 Shutoff valve
EN-14
circuit 3 /
452162.66.25-EN · FD 0402
HWK 332HC
