Requirement: Torque
Screws: Level 1 - 19
Drilling: -
Hammer-drilling: -
8.8 On/Off switch (10) (Fig. 1)
The speed can be steplessly controlled by the on/off
switch. The further you press the on/off switch, the higher
the speed.
1. To switch on the product, push the on/off switch (10).
2. To switch off, release the on/off switch (10).
If you put the direction of rotation switch (11) in the
centre position, the product is secured from being
switched on.
8.8.1 LED work lamp (9) (Fig. 1)
This product is equipped with an LED work lamp to illumi-
nate the immediate work area and improve visibility in
poorly lit environments.
CAUTION
Do not look directly into the LED work lamp or the light
source.
1. The LED work lamp (9) lights up automatically as
soon as the product is switched on.
Note:
The LED work lamp remains lit up for approx. 10 seconds
after the product is switched off.
9 Cleaning and maintenance
WARNING
Have maintenance and repair tasks that are
not described in this operating manual, car-
ried out by a specialist workshop. Use only
original spare parts.
There is a risk of accident! Always perform
maintenance and cleaning work with the bat-
tery removed. There is a danger of injury! Let
the Product cool down before all mainte-
nance and cleaning tasks. Elements of the
engine are hot. There is a danger of injury
and burning!
The product can start unexpectedly and cause injuries.
– Remove the battery.
– Allow the product to cool down.
– Remove the tool attachment.
9.1 Cleaning
1. Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend that
you clean the product directly after every use.
20 | GB
2. Ventilation openings must always be free.
Operating mode:
3. Do not use any cleaning products or solvents; they
Screw setting
Drill setting
Hammer-drill
4. Wipe any dirt off the lens with a dry cloth. Be careful
setting
9.2
The product is maintenance-free.
10 Storage
Preparation for storage
1. Remove the battery.
2. Clean and check the product for damage.
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
11 Repair & ordering spare parts
With this product, it is necessary to note that the following
parts are subject to natural or usage-related wear, or that
the following parts are required as consumables.
ATTENTION
According to the German Product Liability Act, no liabili-
ty is accepted for damage caused by improper repairs
or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialists. The same applies to
accessory parts.
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the front
page.
11.1
Please provide the following information when ordering
spare parts:
Spare parts / accessories
Battery pack SBP2.0 - Article no.:
Battery pack SBP4.0 - Article no.:
Battery charger SBC2.4A - Article no.:
Battery charger SBC4.5A - Article no.:
Battery charger SDBC2.4A - Article no.:
Battery charger SDBC4.5A - Article no.:
StarterKit SBSK2.0 - Article no.:
StarterKit SBSK4.0 - Article no.:
www.scheppach.com
could attack the plastic parts of the product. Make
sure that no water can penetrate the product interior.
to avoid scratching the LED lamp as this can severely
reduce the light intensity.
Maintenance
Ordering spare parts
• Model designation
• Item number
• Type plate data
7909201708
7909201709
7909201710
7909201711
7909201712
7909201713
7909201720
7909201721
