Table of contents
1
Introduction ........................................................
2
Product description (fig. 1) .................................
3
Scope of delivery (Fig. 1) ...................................
4
Proper use..........................................................
5
Safety instructions..............................................
6
Technical data....................................................
7
Unpacking ..........................................................
8
Operation ...........................................................
9
Cleaning and maintenance ................................
10 Storage...............................................................
11 Repair & ordering spare parts ............................
12 Disposal and recycling .......................................
13 Troubleshooting .................................................
14 Warranty conditions - Scheppach 20V IXES se-
ries .....................................................................
15 EU Declaration of Conformity.............................
16 Exploded view .................................................... 223
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Wear safety goggles.
Wear hearing protection.
If dust builds up, wear respiratory protection!
Screwing
Drilling
14 | GB
14
14
15
15
15
17
18
1
Introduction
18
Manufacturer:
20
Scheppach GmbH
20
Günzburger Straße 69
20
D-89335 Ichenhausen
21
Dear Customer
21
We hope your new product brings you much enjoyment
and success.
21
Note:
23
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product as
described and for the specified areas of application. Keep
the operating manual in a good place and hand over all
documents when passing the product on to third parties.
2
Product description (fig. 1)
1.
Chuck opening
2.
Quick-release chuck
3.
Torque adjusting ring
4.
Mode selection adjusting ring
5.
Gear selector switch
6.
Battery*
7.
Battery mount
8.
Release button (battery)
9.
LED work lamp
10.
On/off switch
11.
Rotational direction switch
12.
Belt clip
13.
Screw
* = not included in the scope of delivery!
www.scheppach.com
Hammer-drilling
Lithium-ion battery
The product complies with the applicable
European directives.
