EN
2.4.5.1. Programming of the pre-programmed somfy io-homecontrol® local control
point
Press the PROG button of the pre-programmed control point: the driven product
performs a brief back and forth movement; the control point is programmed
definitively.
2.4.5.2. Programming of a non pre-programmed control point
1] Switch off the power supply (the pre-programmed control point is deleted).
2] Switch the mains power supply back on. The motorised product moves back
and forth briefly.
3] Simultaneously press the Up and Down buttons of the control point to be
programmed until the motorised product moves briefly.
4] Briefly press the PROG button of this control point: the motorised product
performs a brief back and forth movement; the control point is programmed.
2.5.Tips and advice on installation
2.5.1.Questions about the product?
Observations
The motorised product does not
operate.
The motorised product does not
respond to the wake-up command.
2.5.2.Resetting of the manual end limit setting only
1] Reach the end limit position to modify.
2] Press the Up and Down buttons simultaneously until the motorised product
briefly moves back and forth.
3] Reach a new desired end limit position.
4] Press and hold the My button until the motorised product briefly moves back
and forth.
g The new end limit position is now programmed and the old one is deleted.
8
Possible causes
The wiring is incorrect.
The control point battery is low.
The control point is not compatible.
The control point used has not been
programmed into the drive.
The motorised product is not set.
1]
3]
Solutions
Check the wiring and modify it if
necessary, referring to Wiring.
Check the battery and replace it as
required.
Check the compatibility and replace the
control point if necessary.
Use a programmed control point or
program this control point, referring to
Programming the control point.
Proceed to section Commissioning.
1]
2]
4]
©
Copyright 2021 SOMFY ACTIVITES SA. All rights reserved.
Pergola io LOUVER CONTROL
PROG
2]
4]
PROG
3]
