Pergola io LOUVER CONTROL
2.5.3.Adding/Deleting a control point
NOTICE
• First one-way io control point: This control is already programmed at the outputs concerned which will not be
cleared.
• Second one-way io control point: This control point must be programmed or cleared at the same outputs as
transmitter 1.
1] Press the PROG button on the back of the first io control point for more than
2 seconds until the motorised product makes back and forth movement on
the output concerned.
2] Briefly press the PROG button on the back of the second io control point
until the motorised product makes back and forth movement on the output
concerned.
2.5.4.Sensors
NOTICE
• To customise the setting of the sensors, use the Set&Go io tool (contact a Somfy representative for more
information).
• To find compatible products, contact a Somfy representative.
• This chapter describes the default behavior of the sensors.
2.5.4.1. In case of freeze
NOTICE
For freeze detection, this box has an internal temperature sensor.
The pergola goes to its « Freeze position » if the current position is under this position.
Default « Freeze position »: 90% CLOSED (Open at 10° approximatively)
Default temperature of detection: 5°C
Refer to Set&Go io Somfy product to customise the internal temperature
sensor:
▪ The position: settable between 0 to 100%.
▪ The threshold: settable between 0°C to 8°C.
▪ The status: activation/deactivation.
NOTICE
Automatic and manual movements are authorized, but if a position under the "Freeze position" is requested, the
pergola goes into this position and then immediately returns to "Freeze position".
2.5.4.2. In case of rain
NOTICE
For rain detection, use a wired rain sensor, directly connected to the box.
The pergola goes to its « Rain position ».
Default « Rain position »: 100% CLOSED
Refer to Set&Go io Somfy product to customise:
The rain position: settable between 0 to 100%.
NOTICE
• Automatic and manual movements are authorized.
• The sensor is deactivated if the Auto/Manu button of the situo Variation is
on « manual mode ».
©
