Pergola io LOUVER CONTROL
1] Set the driven product to the desired "my" position.
2] Press my button until the motorised product moves up and down briefly: the
new "my" position is programmed and the old "my" position is deleted.
3.3.Tips and advice on operation
3.3.1.Questions about the product?
Observations
The motorised product does not operate.
NOTICE
If the motorised product still does not operate, contact a drive and home automation professional.
3.3.2.Replacing a lost or broken Somfy control point
To replace a lost or broken control point, contact a drive and home automation professional.
4.TECHNICAL DATA
Power supply
Radio frequency
Frequency bands and maximum power used
Index protection rating
Operating temperature
Electrical insulation
Frequency
Drive current
Maximum number of associated control points by drive
Maximum number of associated sensors by drive
Dimension in mm
Minimum cycle life requirement
Type of control
Control-command
Pollution degree
PRECAUTION
Do not set the maximum current more than 50% of the nominal current of the motorisation. Maximum current is
settable with Set&Go product between 0.5 A and 5.5 A (Default = 3 A) depending of the drive used.
Drives are not designed to resists to a too exceed current.
If the needed current exceeds 50% of the nominal one, check the accordance between the drive 's powerful and the
maximum force needed to move the slates (Weight, friction, temperature,...)
NOTICE
For additional information on the technical data for this drive, contact your Somfy representative.
©
Copyright 2021 SOMFY ACTIVITES SA. All rights reserved.
Possible causes
The control point battery is low.
24 V DC SELV +/- 2%
868-870 MHz
868.000 MHz - 868.600 MHz e.r.p. <25 mW
868.700 MHz - 869.200 MHz e.r.p. <25 mW
869.700 MHz - 870.000 MHz e.r.p. <25 mW
IP55
-20°C to +70°C
Class III
Continuous current
From 0.5 to 5.5 A
9
3
80 x 265 x 45
10000
1.Y
Class A
3
1] 2]
Solutions
Change control point battery as
required.
