The Info menu
Display
Version
Capacity
Hardware
Power supply:
Power consumption:
DMX channels:
Storable scenes/chases:
DMX512 output:
Sound-control:
Available storage media:
Storage connection:
5V charging connection:
Dimensions (W x D x H):
Weight:
Specifications are subject to change without notice due to product improvements.
Pin connection:
In the <Info> menu, you can view system information.
Function
Here you can see which firmware version is installed on your DMX Commander
512.
Here you can see how many program steps are available. A lighting program
can have any number of steps (cues). A total of 767 steps are available.
This option can be used to check if the console's buttons are working correctly.
The LED should light up when you press a button in this mode (with the
exception of ESC).
TECHNICAL SPECIFICATIONS
100-240 V AC, 50/60 Hz
<10 W
512
767 cues distributed over 57 pages
3- and 5-pin XLR mounting socket
via built-in microphone or line input (6.3 mm jack)
USB devices (FAT32)
USB-A
USB-A
482 x 266 x 80 mm
Rack installation with 6 U
4.7 kg
38 • EN
