Operating buttons

Button
MENU
▲ ▲ ▲ ▲
▼ ▼ ▼ ▼
ESC
Network settings in the <NetworkSettings> menu
Indication
<IP1 Address>
<IP2 Address>
<Subnet Mask>
Configuration of the ports in the <DMXOutSettings> menu
Indication
<DMX OUT>
<DMX Hold>
Device settings in the <System> menu
Indication
<Firmware>
<DisplayBacklight>
<FactoryReset>
Function
Calls the menu and the next menu item and Activates a value to be modified.
Selects the next menu item and increases values when modifying.
Selects the previous menu item and decreases values when modifying.
Exits the current level and returns to the start display.
Parameter Function
xxx.xxx.xxx.xxx Input of the IP address of node 1.
The device is separated in 2 nodes according to the Art-Net
specification. Each node uses its own IP address for unique
identification in the network. DMX outputs 1-4 are assigned to node 1
and DMX outputs 5-8 to node 2. Use the IP address ranges 2.x.x.x or
10.x.x.x according to the Art-Net specification.
xxx.xxx.xxx.xxx Input of the IP address of node 2.
255.0.0.0 Input of the subnet mask.
Leave the subnet mask at 255.0.0.0 according to the Art-Net
specification.
Parameter Function
DMX OUT 1-8 Signal routing for DMX outputs 1-8.
Select <DMX A> or <DMX B> for signal input via one of the DMX
inputs or <ArtNet> for Art-Net operation. For Art-Net, set the <Net>,
<SubNet> and <Univ> parameters according to the Art-Net
specification in the submenu.
DMX Hold 1-8 Output behavior for DMX outputs 1-8 on loss of the DMX signal.
<Yes>: The last correct DMX data is sent. <No>: There is no DMX
data output.
Function
Indication to the firmware version.
Display illumination.
<Yes>: Display backlight is always on. <No>: Display backlight off after 30 sec.
Rest to default settings.
