No. Description
8 CAM4 socket
VCC cable (red): Connection to 10 ... 32 V, the switched plus of the ignition (connected positive, terminal 15)
9
or the positive pole of the battery (terminal 30)
10 Trigger1: Trigger connection cable to activate the selected camera
11 GND cable (black): Connection to ground
12 Trigger2: Trigger connection cable to activate the selected camera
13 Trigger3: Trigger connection cable to activate the selected camera
14 Trigger4: Trigger connection cable to activate the selected camera
Trigger5 control cable (yellow): Split control cable for activating the split screen (the screen is divided into 2
15
parts with any 2 cameras)
16 Video output socket (yellow): Live video output
8.1.5 Connecting the monitor as a reversing video system
1. Lay the monitor cable on the dashboard.
2. Insert the monitor cable plug
page 17,3) of the connection cable
NOTICE! Damage hazard
Ensure that the polarity is correct when connecting to a voltage source.
3. Connect the power cable (red)
4. Connect the earth cable (black)
5. If the monitor is to be activated when the reverse gear is engaged, connect the trigger cable selected to ac-
tivate the rear camera
8.1.6 Connecting the split screen control cable
The connection of the Trigger5 control cable
Connect the Trigger5 control cable (yellow) to a 10 ... 32 V voltage signal.
9

Operation

NOTICE! Damage hazard
Do not apply strong pressure when operating the touchscreen.
18
(Fig.  on page 17,2) in the connection cable socket
(Fig. 
(Fig.  on page 17,9) to terminal 15 (ignition).
(Fig.  on page 17,11) to terminal 31 (ground).
(Fig.  on page 17,10, 12, 13, 14) to the positive cable of the reversing light.
(Fig. 
on page 17,4).
on page 17, 15) activates the split screen.
(Fig.  on
