Camera modes

1 – 4 camera images can be displayed on the monitor. The camera images are placed in layers.
Order Icon Name
1 Camera 1
2 Camera 2
3 Camera 3
4 Camera 4
5 Dual
6 Triple
7 Trefoil
8 Y-Split
9 H-Split
10 Quad
11 PIP1
12
Description
The image of the camera connected to CAM1 is displayed.
The image of the camera connected to CAM2 is displayed.
The image of the camera connected to CAM3 is displayed.
The image of the camera connected to CAM4 is displayed.
2 camera images are displayed.
3 camera images are displayed.
On the le side of the monitor a large view of 1 camera image is displayed. 1 camera im-
age is shown in the upper right corner and 1 in the lower right corner of the monitor.
3 camera images are displayed.
1 camera is placed in the center of the upper area of the monitor. 1 camera image is
placed in the lower le and 1 in the lower right corner of the monitor.
3 camera images are displayed.
1 camera image is displayed in the upper le and 1 in the upper right corner of the moni-
tor. 1 camera image is placed in the center of the lower area of the monitor.
4 camera images are displayed.
1 camera image is displayed on the le and 1 on the right side of the monitor. 1 camera
image is displayed in the upper and 1 in the lower center of the monitor.
4 camera images are displayed.
1 camera image is displayed in each corner of the monitor.
4 camera images are displayed.
On the le side of the monitor a large view of the camera image connected to CAM1 is
displayed. In front of the camera image of CAM1 the camera image of the camera con-
nected to CAM4 is displayed in the center of the lower area.
The camera image of the camera connected to CAM2 is displayed in the upper right
corner of the monitor. The camera image of the camera connected to CAM3 is dis-
played in the lower right corner of the monitor.
The camera images can be customized with additional settings (see
a mode on page 22). Some operating functions are blocked (see
touchscreen functions on page 21).
