Prefix / Adjustment output function

Adjustment with EasyTeach by Wire (ETW):
The menu for the output functions starts by activating the EasyTeach connection (Teach wire / Teach
pin with the supply voltage UB+) before switching on the supply voltage. By continuing to hold the
EasyTeach connection actively the menu goes through the various tiers of the output functions in an
infinite loop. The menu always starts with the output function antivalent and changes every 5 seconds.
The desired output function is set by disconnecting the wire.
Adjustment with EasyTeach by Button (ETB):
The menu for the output functions starts by pushing the EasyTeach button before switching on the
supply voltage. By continuing to push the EasyTeach Button the menu goes through the various tiers
of the output functions in an infinite loop. The menu always starts with the output function antivalent and
changes every 5 seconds. The desired output function is set by releasing the EasyTeach button.
Adjustment with EasyTeach by Magnet (ETM):
The menu for the output functions starts by holding the EasyTeach magnet on the EasyTeachspot
before switching on the supply voltage. By continuing to hold the EasyTeach magnet on the
EasyTeachspot the menu goes through the various tiers of the output functions in an infinite loop. The
menu always starts with the output function antivalent and changes every 5 seconds. The desired output
function is set by removing the EasyTeach magnet.
Output function
Antivalent*
2 x Normally open
2 x Normally closed
Attention:
When switching the output function from Normally Open / Normally Closed to antivalent, S2
will be faded out. The adjusted S1 switches antivalent then. When switching back to normally
open / normally closed S2 has the pre-adjusted value.
Optical representation
LED flashes green yellow
LED flashes green
LED flashes yellow
*Delivery configuration
23
