Mounting
"Zone without
Fig.1
detectable material
Flush mountable
Fig.3
Two opposite sensors have to be mounted with a distance of at least 2.2 times of the oper-
ating distance (distance "a").
i
For non flush mountable sensors, the zone without a thread has to be mounted with a dis-
tance of at least 1.5 times of the operating distance from the damping material (distance "b").
*If this dimension is reduced, the sensitivity is reduced.

Pin connection

Pin connection for pluggable sensors (top view)
3
4
1 2
20
Free zone ≥ 3 x d
a thread"
Diameter "d"
Fig.2
Mounting /
Non-flush mountable
a
b
Fig.4
4
5
1
KAS-...-26/...-...-G1-...
KAS-...-26/...-...-G1/2-...
3
i
Pin 5 is only available for
sensors with ETW-function.
2
min. 25 mm*
min. 15 mm*
