Utilization of the PROGRAMMER-Box
as self contained unit:
Utilization of the PROGRAMMER-Box as self contained unit:
1. Measurement of receiver channel output pulse widths
2. Servo pulse generator
3. Servo cycler
4. Measurement of servo transfer speeds
5. Communication with Compact Control ..S controllers
For application #1 you need a receiver, transmitter and receiver battery (4.8...6V). Plug
batteries into socket GRAY, receiver to socket BLUE, both on the right side of the PRO-
GRAMMER-Box.
For application #2, #3 and #4 you need a receiver battery (4.8...6V) and a servo. Connect
the receiver battery to the socket first GRAY and the servo to socket BLUE.
In case of change of the application you must disconnect the supply battery from the
PROGRAMMER-Box and activate them again. In order to choose the required application
use the push-buttons R and L.
1. Measurements of receiver channel output pulse widths
By means of this application the width of the output pulse of any arbitrary RX channel
output can be measured. Furthermore, measurement of the receiver battery supply voltage
is also possible.
Connect the receiver batteries to the receiver. With the aid of connecting cable as
delivered along with the PROGRAMMER-Box connect socket BLUE with a definite RX
channel output. Switch on the transmitter and receiver. The display shows now IMPULS
DETECTION and you can read the values of the output pulse width in ms and the RX
battery voltage.
2. Servo pulse generator
This PROGRAMMER-Box application renders the generation of servo controlling pulses
as well as the measurement of the servo supply voltage possible. By means of the push-
buttons you can change the range from 1.024ms to 2.047ms either in steps of thousandth
or hundreds of a ms. This function is for instance very well suited for setting the centre po-
sition of a servo (1.500ms) without receiver and transmitter. Connect batteries and servo.
The pulse width can be set by means of all four push-buttons:
With push-button L the pulse becomes narrower in steps of 0.001ms
With push-button D the pulse becomes narrower in steps of 0.01ms
With push-button U the pulse becomes wider in steps of 0.01ms
With push-button R the pulse becomes wider in steps of 0.001ms
Utilization of the PROGRAMMER-Box as self contained unit
