Setting with the help of the PROGRAMMER-Box #7200
Setting with the help of the PROGRAMMER-Box #7200
This setting is carried out by means of four push-buttons: left L, right R, up U, down D.
Plug in the JR connector of the controller into the plug designated Impuls + -, which is positioned on the right side of the
PROGRAMMER-BOX.
Before connecting the flight battery remove for the sake of safety the propeller.
Do not connect anything to the connector designated with -+ .
Connect the flight batteries and switch on the switch. On the display appears the name of the connected controller. By
means of the push-buttons L and R more detailed information are acquired of your controller.
By means of the push-button D we get to the option line of basic regimes where we either can choose reading out of
measured values or setting of controller parameters (Measure or Setting), with push-buttons L and R we choose
MEASURE – MAN. SETTING – AUTO SET.
Messure
D
Max. Temperature
D
Min. Temperature
D
Actual Temperature
D
Max. Current
D
Min. Current
D
Max. Voltage
D
Min. Voltage
D
Actual Voltage
D
Off Voltage
MEASURE – continue with push-button D
The controller registers the max. temperature during operation and the time of its occurrence.
The time measurement begins with the first revolution of the motor.
The controller registers the min. temperature during operation and the time of its occurrence.
The display indicates the actual temperature.
The controller registers the max. current at full throttle, the time at which this value occurred and
the voltage of the flight batteries corresponding with this current. The measured value corre-
sponds to the current peak which mostly occurs when the motor is abruptly accelerated.
The controller registers the min. current at full throttle, the time at which this value occurred and
the voltage of the flight batteries corresponding with this current. The measured value corre-
sponds to the minimum current at full throttle which mostly occurs at horizontal or descending
flight, when the motor is unloaded.
The controller registers the max. voltage of the flight batteries beginning with the first revolution
of the motor as well as the time when this value occurred.
The controller registers the min. voltage of the flight batteries beginning with the first revolution of
the motor as well as the time when this value occurred.
Instantaneous battery voltage.
Value at which the motor has been switched off or its power throttled down as well as the time,
at which this value occurred.
ID # 0058019
Flowchart 17
