light-output very quickly. The cooling-fans should be cleaned monthly.
To ensure a proper function of the gobo-wheel, we recommend lubrication in six month intervals. The
quantity of oil must not be excessive in order to avoid that oil runs out when the gobo-wheel rotates.
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuseholder on the rear panel with a fitting screwdriver from the housing (anti-
clockwise).
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
DMX control channels:
DMX512 connection:
Sound-control:
Flash-rate:
Number of LEDs:
LED type:
Beam angle:
Maximum PAN-movement:
Maximum TILT-movement:
Dimensions (LxWxH):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
Accessory:
TPC-10 Coupler, black
TH-50S Theatre clamp bk
Safety bond B 4x1000mm up to 15kg, black
Safety bond 3x600 black
DMX operator 192 controller
DMX cable XLR 3pin 3m bk
DMX cable XLR 3pin 5m bk
DMX cable XLR 3pin 10m bk
DMX cable XLR 3pin 15m bk
DMX cable XLR 3pin 20m bk
100-240 V AC, 50/60 Hz ~
220 W
15/16/17/24
3-pin XLR
via built-in microphone
18 Hz
36
7 W QCL
13° - 60°
unlimited
unlimited
179 x 343 x 430 mm
8.5 kg
:
45° C
a
(steady state):
70° C
C
0.5 m
0.3 m
T 2 A, 250 V
No. 59006858
No. 58000651
No. 58010345
No. 58010252
No. 70064520
No. 30227810
No. 30227812
No. 30227814
No. 30227816
No. 30227818
48/52
00083593.DOC, Version 1.0
