2 Channel Mode
Channel:
Value:
1
000 – 255
Channel:
Value:
2
000 – 255
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuseholder with a fitting screwdriver from the housing (anti-clockwise).
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only
in order to avoid hazards.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Number of channels:
DMX-512 connection:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces: 0.5 m
Min. distance to lighted object:
Type of LEDs:
Number of LEDs:
Beam angle:
Fuse:
Dimensions (LxWxH):
Weight:
Please note: Every information is subject to change without prior notice. 03.08.2010 ©
Function:
Warm white (0 – 100%)
Function:
Cool white (0 – 100%)
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
230 V AC, 50 Hz ~
90 W
max. 4
3-pin XLR
via built-in microphone
:
45° C
a
:
55° C
B
0.1 m
1 W
36
22°
F 2 A, 250V
295 x 275 x 400 mm
2.5 kg
21/21
00051972.DOC, Version 1.1
