The fixture's base enables to be mounted in two ways.
The Moving-Head can be placed directly on the stage floor or rigged in any orientation on a truss without
altering its operation characteristics (see the drawing).
For overhead use (mounting height >100 cm), always install an appropriate safety bond.
You must only use safety bonds complying with DIN 56927, quick links complying with DIN 56927, shackles
complying with DIN EN 1677-1 and BGV C1 carbines. The safety bonds, quick links, shackles and the
carbines must be sufficiently dimensioned and used correctly in accordance with the latest industrial safety
regulations (e. g. BGV C1, BGI 810-3).
which is defective must not be used again.
Before taking into operation for the first time, the installation has to be approved by an expert!
Please note: for overhead rigging in public or industrial
areas, a series of safety instructions have to be followed
that this manual can only give in part. The operator must
therefore
inform
instructions and consider them.
The manufacturer cannot be made liable for damages
caused by incorrect installations or insufficient safety
precautions!
Install the safety bond by inserting the quick link in the
attachment eyelet on the bottom of the base. Pull the
safety bond over the trussing system etc. Insert the end
in the quick link and tighten the fixation screw.
The maximum drop distance must never exceed 20 cm.
A safety bond which already hold the strain of a crash or
DANGER TO LIFE!
(1) Omega-holder
(2) Clamp
(3) Safety-rope
(4) Quick-lock fastener
34/52
himself
on
the
current
00083593.DOC, Version 1.0
