System require- As regards the installation of the PushPull unit, only welding sets equipped with
ments
a SR41 pc board may be converted on the spot. Sets with a SR40 pc board may
be converted in our factory only.
For proper operation of the PushPull unit, software 2.50.25 or higher ( power
source) and 1.30.01 or higher (wire feeder) is required.
Components
Installation kit "PushPull-Unit (PullMIG)"
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
16
(1)
1 x pc board PM41A
1 x board feeder cable harness
1 x motor feeder cable harness
1 x motor feeder extension
4 x cable tie
1 x hex-nut
1 x serrated lock washer
2 x plastic spacer block
(2) (4)
(8) (7) (6) (3)
(5)
