Operation and Display Elements

Figure 1 – Overview of operation and display elements.
No. Description
① Miniature sensor tip
② Power Button
③ LCD display showing the conductivity value
Conductivity scale 0 – 62 MS/m: graphical display of the
④ conductivity. No direct information on the authenticity
of the test object.
⑤ Display „Ready": You can start with your measurement.
Indication of low battery charge level: This warning is
⑥
only shown when the device is switched on!
Indication of ferromagnetic metal: Ferromagnetic
⑦
objects cannot be measured!
Indication of a metal contact of the probe tip during
⑧
startup.
