Operation and Display Elements

22
Figure 1 – Overview of operation and display elements
Nr. Beschreibung
① Miniature-sensor tip
② Power Button
③ LCD display showing the conductance value
Conductance scale 0 – 62 MS/m, represents
conductance graphically. No direct statement about
④
authenticity of testing sample.
⑤ Display „Ready": You can start with your measurement
Advice on low battery: This advice is shown after
⑥
switching on the device only!
Advice on ferromagnetic specimen: Ferromagnetic
⑦
objects cannot be measured!
Advice on metal contact of the sensor tip while starting
⑧
process. Please remove the metal from the tip.
Table 2 – Description of operation and display elements
