9 Supplement
LEVEL SWITCH 8112
Fig. 29: LEVEL SWITCH 8112
1
Thread
2
Clamp
3 Cone DN 25
4 Bolting DN 40
5
Flange
6
Gas-tight leadthrough
7
Temperature adapter
L = Sensor length, see chapter "Technical data"
34
32 (G 3 / A, 3 / "NPT)
4 4
41 (G1A, 1"NPT)
3 3
G / A, / "NPT
4 4
G1A, 1"NPT
1
ø 33,7 mm
(1.33")
4
2
5
LEVEL SWITCH 8112 • with transistor output
3
6
